FOUR-PILING BOAT LIFTS

Tide Tamer four-piling boat lifts are built for waterfront owners who need a stable, dependable lift system for everyday boat storage in saltwater environments.

Designed for fixed dock applications and standard four-piling layouts, these lifts use a traditional cable-driven, shafted beam system to raise your boat securely out of the water and keep it protected between uses.

MEET WITH AN INSTALLER View Specifications

Proven Boat Lift Performance for Fixed Docks and Coastal Conditions

With capacities from 5,000 to 24,000 lbs, Tide Tamer four-piling lifts are a proven choice for center consoles, bay boats, pontoons, cruisers, and other recreational boats used along the North Carolina coast, East Coast, and other demanding waterfront environments.

Built with marine-grade aluminum, stainless steel components, direct-drive gear units, machined parts, and fully adjustable support systems, these lifts are engineered for long-term coastal performance.

Quick Overview

  • Best for: Fixed dock installations and standard four-piling layouts

  • Capacity range: 5,000 to 24,000 lbs

  • Common applications: Center consoles, bay boats, pontoons, cruisers, and recreational boats

  • Water conditions: Coastal environments with tidal changes, wake, and daily exposure

  • System type: Cable-driven lift mounted to four dock pilings

  • Customization: Available with multiple configurations, controls, accessories, and add-ons

Built for Fixed Docks, Changing Tides, and Daily Use

If your boat sits at a fixed dock, you already know how much the environment matters.

Changing tides, passing wake, saltwater exposure, humidity, and long-term sun can take a toll on both your boat and your equipment. A properly built boat lift is not just about convenience. It helps protect your investment, simplifies your routine, and gives you confidence every time you return to the dock.

Four-piling lifts are one of the most common and reliable lift configurations used across coastal waterfront properties because they offer a strong balance of stability, capacity, serviceability, and long-term performance.

For many boat owners, this is where the search starts.

How Four-Piling Boat Lifts Work

Four-piling lifts use a cable-driven system mounted to four dock pilings to raise and lower your boat out of the water.

The lift structure distributes weight across the pilings, top beams, cradle beams, bunks, and cable system. This helps keep your boat stable, properly supported, and positioned above the waterline when not in use.

As lift capacity increases, the system is reinforced with larger beams, stronger bunks, and multi-pull cable configurations to help maintain smooth operation and reliable performance under heavier loads.

That is why choosing the right four-piling lift is about more than boat weight alone. Your dock layout, piling size, beam spacing, water depth, boat dimensions, hull type, and weight distribution all matter.

Why Many Waterfront Owners Choose Four-Piling Lifts

Four-piling lifts are popular for a reason: they are proven, familiar, and effective for a wide range of waterfront applications.


A Proven Lift Configuration

The four-piling structure provides a stable lifting platform for many mid-size to larger recreational boats, including center consoles, bay boats, pontoons, and cruisers.

ChatGPT Image May 8, 2026, 09_40_45 AM (1).png

Built for Coastal Conditions

Tide Tamer four-piling lifts are designed for saltwater environments, using aluminum and stainless steel components that help stand up to long-term marine exposure.

ChatGPT Image May 8, 2026, 09_40_45 AM (2).png

Flexible System Options

With multiple capacities, cable configurations, beam sizes, bunks, controls, and accessories available, these systems can be configured around your boat and dock setup.


Long-Term Confidence

A properly matched and installed four-piling lift helps protect your boat, reduce time in the water, and make each trip easier from start to finish.

Key Features

Marine-Grade Aluminum Construction: Tide Tamer four-piling lifts are built with 6061 T6 marine-grade aluminum, providing strong, corrosion-resistant structural support for coastal environments.

Stainless Steel Components: Stainless steel piling mount brackets, lifting cables, and hardware help support long-term performance in saltwater conditions.

Direct-Drive Gear Units: Direct-drive gear units provide smooth, dependable lifting performance without unnecessary mechanical complexity.

Stainless Steel Motors: Tide Tamer four-piling lifts use stainless steel electric motors built for repeated use in demanding marine environments.

American Standard Structural Top Beams: Structural top beams provide the strength and support needed for stable lifting across a range of boat sizes and capacities.

Aluminum Grooved Cable Winders: Grooved cable winders help support smooth cable movement and consistent lifting operation.

Adjustable Cable Clamp System: The adjustable cable clamp system supports proper setup and alignment during installation.

Fully Adjustable Cradle: A fully adjustable cradle helps position the boat properly and support the hull based on the vessel’s shape and weight distribution.

Aluminum or Nylon Pulleys: Depending on configuration, Tide Tamer four-piling lifts may use aluminum or nylon pulley components designed for smooth operation.

Available Engineered Sealed Drawings: Engineered sealed drawings are available with lift purchase, helping support properly specified projects where documentation is required.

What Sets This Design Apart

Four-piling lifts are widely used, but not every four-piling lift is built the same.

Tide Tamer focuses on structural strength, proven materials, precision-built components, and practical long-term performance in coastal environments. The piling-mounted design provides a stable lifting platform, while the cable system, cradle, bunks, and drive components work together to raise and store your boat safely above the waterline.

For waterfront owners, that means less uncertainty at the dock.

For contractors and installers, it means a familiar, proven lift configuration with the technical options needed to match a wide range of projects.

Technical Specifications

Four Piling Boat Lift Specifications

Four piling lifts are engineered differently as capacity increases. Use the table below to compare beam sizes, cable configurations, drive details, motor requirements, and minimum piling sizes.

Scroll sideways to view all specifications.

Specifications are provided for general comparison. Final lift selection should account for boat weight, center of gravity, water conditions, and installation requirements.
Capacity Top Beam Cradle Beam Bunks Cable Size / Pull Drive Motor Drive Shaft Minimum Piling
5,000 lb. 5 in. channel x 12 ft. 6 in. 4 in. x 6 in. x 10 ft. 8 in. aluminum 5/16 in. SS 7/19 (.313) Single pull Direct drive 3/4 H.P. Qty. 2 220V, 4.9A each 1-1/2 in. Sch. 40 8 in. Qty. 4
7,000 lb. 6 in. channel x 12 ft. 6 in. 4 in. x 6 in. x 12 ft. 6 in. 8 in. aluminum 5/16 in. SS 7/19 (.313) Single pull Direct drive 1 H.P. Qty. 2 220V, 6.8A each 1-1/2 in. Sch. 40 8 in. Qty. 4
10,000 lb. 7 in. channel x 12 ft. 6 in. 5 in. x 8 in. x 12 ft. 6 in. 8 in. aluminum 5/16 in. SS 7/19 (.313) Double pull Direct drive 3/4 H.P. Qty. 2 220V, 4.9A each 1-1/2 in. Sch. 40 8 in. Qty. 4
13,000 lb. 7 in. channel x 12 ft. 6 in. 5 in. x 8 in. x 12 ft. 6 in. 8 in. aluminum 5/16 in. SS 7/19 (.313) Double pull Direct drive 1 H.P. Qty. 2 220V, 6.8A each 1-1/2 in. Sch. 40 8 in. Qty. 4
16,000 lb. 8 in. channel x 12 ft. 6 in. 6 in. x 10 in. x 14 ft. 10 in. aluminum 5/16 in. SS 7/19 (.313) Double pull Direct drive 3/4 H.P. Qty. 2 220V, 4.9A each 1-1/2 in. Sch. 40 10 in. Qty. 4
20,000 lb. 9 in. channel x 14 ft. 6 in. 6 in. x 10 in. x 15 ft. 10 in. aluminum 5/16 in. SS 7/19 (.313) Triple pull Direct drive 3/4 H.P. Qty. 2 220V, 4.9A each 1-1/2 in. Sch. 40 10 in. Qty. 4
24,000 lb. 9 in. channel x 14 ft. 6 in. 7 in. x 12 in. x 16 ft. 10 in. aluminum 5/16 in. SS 7/19 (.313) Triple pull Direct drive 1 H.P. Qty. 2 220V, 6.8A each 1-1/2 in. Sch. 40 10 in. Qty. 4

Helpful context: Single-pull cable configurations are used on the lower-capacity models, double-pull configurations begin at 10,000 lb., and triple-pull configurations are used on the 20,000 lb. and 24,000 lb. models.

Engineering note: Load should always be evenly distributed across the lifting beams, with the boat’s center of gravity positioned properly. A local Tide Tamer dealer can help confirm the right capacity, piling requirements, and setup for your waterfront conditions.

Learn More:

Four-piling lifts are not one-size-fits-all. The right system depends on your boat’s loaded weight, hull style, dock layout, piling size, and water conditions.

As capacity increases, the structural components and cable systems are scaled to handle greater load demands.

5,000 to 7,000 lb Lifts

Single-pull cable systems

A strong option for lighter boats and simpler waterfront setups where the boat, dock, and piling layout are compatible.

10,000 to 16,000 lb Lifts

Double-pull cable systems

Designed for mid-size boats that require additional lifting power, support, and stability.

20,000 to 24,000 lb Lifts

Triple-pull cable systems

Built for heavier recreational boats and higher-load applications where reinforced components and proper setup become even more important.

As lift capacity increases, beam sizes, cradle dimensions, bunks, motor requirements, cable systems, and piling requirements change to support the additional load.

Four-piling lift components are scaled by capacity to support proper load distribution.

As capacity increases:

  • Top beam sizes increase from 5" to 9" channel beams

  • Cradle beams increase in size and length

  • Bunk size increases from 8" aluminum to 10" aluminum

  • Cable systems move from single pull to double pull to triple pull

  • Minimum piling requirements increase from 8" to 10" on higher-capacity models

This helps ensure the boat’s weight is properly supported across the lift structure instead of concentrated in one area.

Tide Tamer four-piling lifts are designed for dependable lifting performance without unnecessary complexity.

Key drive and power features include:

  • Direct-drive gear units

  • Dual motor configuration

  • 220V power systems

  • Stainless steel electric motors

  • Cable-driven lifting operation

  • Capacity-specific motor sizing

A properly selected drive and power system helps the lift operate smoothly and consistently for the boat it is designed to support.

Four-piling lifts are designed for standard four-piling dock configurations.

Typical requirements include:

  • Four dock pilings

  • Minimum 8" pilings for lower-capacity systems

  • Minimum 10" pilings for higher-capacity systems

  • Proper piling spacing based on lift size

  • Correct alignment for the lift, cradle, and boat center of gravity

Typical spacing varies by system size, with common configurations including 12'6" and 14'6" layouts depending on lift capacity.

Because piling size, spacing, dock construction, and water depth all affect lift performance, your dealer or installer should confirm the proper setup before installation.

Choosing a Lift Based on Capacity Alone

Capacity matters, but it is only part of the decision.

A lift should be matched to your boat’s total loaded weight, hull shape, center of gravity, dock layout, piling spacing, cable setup, and water conditions.

Choosing a lift based only on the advertised boat weight can lead to fit issues, poor load distribution, unnecessary wear, and long-term performance problems.

The right lift should be sized and configured around the full setup — not just the number on the side of the boat.

Tide Tamer four-piling lifts are built for long-term performance and supported by limited warranty coverage.

Warranty coverage may include:

  • Structural components: 10-year limited warranty

  • Gear units: 5-year coverage

  • Electrical components: 1-year coverage

Warranty terms depend on registration, use, installation, maintenance, and the specific product configuration. Review the full warranty documentation for complete details.

Tide Tamer four-piling lifts are designed for long-term coastal performance with straightforward maintenance.

Some components require little to no regular lubrication, while others should be inspected or serviced periodically. The owner’s manual recommends checking lifting cables before and after use, inspecting fasteners and hardware, checking wiring periodically, and maintaining applicable grease points depending on lift type.

For four-piling and eight-piling lifts, aluminum and stainless steel sheaves may require monthly greasing or as needed, and top beam assemblies include grease fittings that should be serviced quarterly or as needed.

Routine inspection helps protect your boat, your lift, and your investment over time.

Four-piling lifts are commonly used for:

  • Fixed docks along coastal properties

  • Standard four-piling dock layouts

  • Areas with moderate tidal movement

  • Waterfronts with passing boat wake

  • Mid-size to large recreational boats

  • Center consoles

  • Bay boats

  • Pontoons

  • Cruisers

  • Coastal North Carolina and East Coast properties

A dealer or marine contractor can confirm whether your dock, piling layout, and water conditions are a good fit.

Four Piling vs Beamless Lifts

Four-piling lifts use a traditional top-beam structure and are a proven choice for many fixed dock applications.

Beamless lifts are often chosen when the owner wants easier boarding, open access, and a cleaner waterfront view without an overhead top beam.

IS THIS THE RIGHT LIFT FOR YOU?

Choosing the right lift depends on your dock layout, boat size, and water conditions. Four piling lifts are a strong, proven option—but making sure it fits your exact setup is key.

A Four-Piling Lift May Be Right If You:

  • Have a fixed dock with a standard four-piling layout

  • Own a mid-size to larger recreational boat

  • Want a dependable, widely used lift design

  • Experience tidal changes or passing boat wake

  • Want a lift system familiar to most marine contractors

  • Need a solution available in multiple capacities and configurations

  • Want long-term boat protection between uses

A Four-Piling Lift May Not Be the Best Fit If You:

  • Have limited or non-standard dock space

  • Need open access without an overhead beam

  • Have an unusually shallow water setup

  • Need to lift a vessel above 24,000 lbs

  • Require a boathouse-specific or yacht-specific lift system

  • Need a more specialized configuration based on site conditions

Not sure if this fits your setup?

Tell us about your boat, dock, and water conditions. We’ll help you determine whether a four-piling lift is the right match.

GALLERY

FIND THE RIGHT FOUR-PILING LIFT FOR YOUR WATERFRONT

Your boat lift should make ownership easier — not more complicated.

Tide Tamer four-piling lifts are built for waterfront owners who want proven performance, reliable boat protection, and a lift system designed for real coastal conditions.

Whether you are replacing an older lift, outfitting a new dock, or trying to confirm the right capacity for your boat, our team can help you choose a system built around your setup.

Tell us about your boat, dock, and water conditions — and we’ll help you take the next step with confidence.

Get My Lift Recommendation Meet With an Installer

Common Questions About Four-Piling Boat Lifts

A four-piling lift is often a strong choice for standard fixed dock layouts with four properly placed pilings. The best way to confirm fit is to have a dealer or marine contractor review your dock layout, piling size, water depth, and boat specifications.

Tide Tamer four-piling lifts are available in capacities from 5,000 to 24,000 lbs. The right size depends on your boat’s total loaded weight, including fuel, gear, batteries, water, and accessories.

Four-piling lifts are commonly used in coastal environments where water levels change due to tides, wake, and weather. Proper lift sizing, piling placement, cable setup, and boat positioning are important for long-term performance.

In many cases, yes — especially if the dock already has a compatible four-piling configuration. A dealer or installer should confirm piling size, spacing, structural condition, and water depth before installation.

Installation time depends on the lift size, dock condition, piling layout, water access, site conditions, and contractor schedule. A local dealer or installer can provide the most accurate timeline for your project.

Four-piling lifts are designed for long-term use with straightforward maintenance. Cables should be inspected before and after use, fasteners and hardware should be checked, wiring should be inspected periodically, and applicable grease points should be serviced according to the owner’s manual.

If your vessel exceeds the four-piling lift capacity range, an eight-piling lift or yacht lift may be a better fit. Tide Tamer offers higher-capacity lift systems for larger vessels.

Yes. Many four-piling lift setups can be paired with canopy systems to help protect the boat from sun, weather, and debris. Your dealer can help confirm sizing and compatibility.

Yes. Four-piling lifts can be configured with different capacities, bunks, controls, remotes, platforms, canopy options, and other accessories based on your boat and waterfront setup.
